Bobcat L285 Large Wheel Loader

The Bobcat® L285 large wheel loader provides top-of-the-line lifting capability and smooth, efficient control with spacious operator comfort to help you outlast the biggest material handling jobs. Three transmission modes help you fine-tune performance to match changing jobsite conditions. A 3-year/5,000-hour full-coverage warranty backs Bobcat quality and durability with extra peace of mind. Joystick controls offer smooth, push-button direction changes, with no need to take your hands off the control.

189 hp

Horsepower

34487 lbs

Operating Weight

24121 lbs

Tipping Capacity

Bobcat L285 Large Wheel Loader

Let's Get Started

"*" indicates required fields

This field is hidden when viewing the form
Newsletter Signup
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form
This field is hidden when viewing the form

Bobcat L285 Large Wheel Loader Specs & Add-Ons

** Listed specs based on machine base model. Actual specs may vary depending on model and options **

Key Specifications

Diesel Exhaust Fluid (DEF) Capacity 7.9 gal
Fuel Tank 62.1 gal
Main Pump Pressure 3844 psi
3rd Spool Max. Flow Rate 66 gpm
3rd Spool Pressure 4351 psi
Main Pump Max. Flow Rate 64.9 gpm
Main Drive Power Shift 4F/4R

Performance

Tipping Capacity with Bucket (Articulated) 24121 lbs
Tipping Capacity with Bucket (Straight) 27364 lbs
Rated Operating Capacity with Forks (Articulated) 7170 lbs
Rated Operating Capacity with Forks (Straight) 8251 lbs
Rated Operating Capacity with Bucket (Articulated) 12061 lbs
Rated Operating Capacity with Bucket (Straight) 13682 lbs
Max. Travel Speed – Forward 22.1 mph
Bucket Capacities 3.5-5.5 yd3 (2.6-4.2 m3)
Operating Weight 34487 lbs
Max. Travel Speed – Reverse 15 mph

Dimensions

Inside Turning Radius With Bucket 243.8 in
Articulation Angle 40 deg
Outside Turning Radius 216.9 in
Length without Attachment 260.6 in
Length with Standard Bucket 315 in
Width (with bucket) 107.9 in
Width (over tires) 103.9 in
Height with Operator Cab 132.2 in
Height to Bucket Hinge Pin 155.5 in
Dump Angle @ Maximum Height 46 deg
Ground Clearance 17 in
Rollback Angle 49 deg
Wheelbase 120 in
Tire Size 20.5R25 L3
Wheel Tread 80.3 in
